文/浙江杰能壓縮設備有限公司
為何使用永磁變頻螺桿壓縮機？
CM螺桿壓縮機采用壓縮機專用變頻器，可靠性高，連續長。
CM/PV系列永磁變頻水潤滑無油螺桿空氣壓縮機技術參數
|
型號 |
工作壓力 |
流量 |
功率 |
噪音 |
重量 |
冷卻水進 |
冷卻水量 |
外形尺寸 |
空氣出口 |
|||
|
MPa |
Psi |
m3/min |
cfm |
kW |
HP |
dB(A) |
kg |
進水332℃ |
L×W×H |
|||
|
T/h |
mm |
|||||||||||
|
CM08PVF |
0.8 |
116 |
0.45-1.15 |
16-41 |
7.5 |
10 |
58 |
630 |
DN25 |
2 |
1550×775×1445 |
1? |
|
1 |
145 |
0.41-1.02 |
14-36 |
500 |
1350×774×1150 |
|||||||
|
CM11PVF |
0.8 |
116 |
0.62-1.55 |
22-55 |
11 |
15 |
58 |
650 |
DN25 |
2.5 |
1550×775×1445 |
1? |
|
1 |
145 |
0.53-1.32 |
19-47 |
520 |
1350×774×1150 |
|||||||
|
1.25 |
181 |
0.48-1.02 |
17-36 |
|||||||||
|
CM15PVF |
0.8 |
116 |
0.96-2.40 |
34-85 |
15 |
20 |
63 |
900 |
DN25 |
3.5 |
1900×1000×1635 |
1? |
|
1 |
145 |
0.85-2.12 |
30-75 |
|||||||||
|
750 |
1680×1000×1335 |
|||||||||||
|
1.25 |
181 |
0.64-1.61 |
23-57 |
|||||||||
|
CM18PVF |
0.8 |
116 |
1.24-3.10 |
44-109 |
18.5 |
25 |
65 |
970 |
DN25 |
4 |
1900×1000×1635 |
1? |
|
1 |
145 |
1.05-2.62 |
37-93 |
|||||||||
|
820 |
1680×1000×1335 |
|||||||||||
|
1.25 |
181 |
0.85-2.13 |
30-75 |
|||||||||
|
CM22PVF |
0.8 |
116 |
1.40-3.50 |
49-124 |
22 |
30 |
65 |
1000 |
DN25 |
5 |
1900×1000×1635 |
1? |
|
1 |
145 |
1.25-3.13 |
44-111 |
|||||||||
|
850 |
1680×1000×1335 |
|||||||||||
|
1.25 |
181 |
1.04-2.61 |
37-92 |
|||||||||
|
CM30PVF |
0.8 |
116 |
2.00-5.00 |
71-177 |
30 |
40 |
66 |
1200 |
DN40 |
7 |
1950×1050×1780 |
1 1/2? |
|
1 |
145 |
1.68-4.20 |
59-148 |
|||||||||
|
1300 |
1900×1050×1430 |
|||||||||||
|
1.25 |
181 |
1.52-3.18 |
54-112 |
|||||||||
|
CM37PVF |
0.8 |
116 |
2.44-6.10 |
86-215 |
37 |
50 |
67 |
1230 |
DN40 |
9 |
1950×1050×1780 |
1 1/2? |
|
1 |
145 |
2.09-5.22 |
74-184 |
|||||||||
|
1320 |
1900×1050×1430 |
|||||||||||
|
1.25 |
181 |
1.92-4.81 |
68-170 |
|||||||||
|
CM45PVF |
0.8 |
116 |
3.12-7.80 |
110-275 |
45 |
60 |
68 |
1930 |
DN40 |
10 |
3040×1280×1800 |
2? |
|
1 |
145 |
2.45-6.13 |
87-216 |
|||||||||
|
1430 |
1880×1260×1430 |
|||||||||||
|
1.25 |
181 |
2.26-5.65 |
80-200 |
|||||||||
|
CM55PVF |
0.8 |
116 |
3.84-9.60 |
136-339 |
55 |
75 |
70 |
2050 |
DN40 |
12 |
3040×1280×1800 |
2? |
|
1 |
145 |
3.44-8.60 |
121-304 |
|||||||||
|
1550 |
1880×1260×1430 |
|||||||||||
|
1.25 |
181 |
2.97-7.42 |
105-262 |
|||||||||
|
CM75PVF |
0.8 |
116 |
5.16-12.90 |
182-455 |
75 |
100 |
73 |
2450 |
DN40 |
18 |
3040×1280×1800 |
2? |
|
1 |
145 |
4.57-11.42 |
161-403 |
|||||||||
|
1790 |
1880×1260×1430 |
|||||||||||
|
1.25 |
181 |
3.93-9.83 |
139-347 |
|||||||||
|
CM90PV |
0.8 |
116 |
6.52-16.30 |
230-576 |
90 |
125 |
73 |
2160 |
DN40 |
20 |
2500×1400×1580 |
2 1/2? |
|
1 |
145 |
5.81-14.52 |
205-513 |
|||||||||
|
1.25 |
181 |
4.92-12.30 |
174-434 |
|||||||||
|
CM110PV |
0.8 |
116 |
7.76-19.40 |
274-685 |
110 |
150 |
78 |
2270 |
DN40 |
24 |
2500×1400×1580 |
2 1/2? |
|
1 |
145 |
6.76-16.90 |
239-597 |
|||||||||
|
1.25 |
181 |
6.04-15.10 |
213-533 |
|||||||||
|
CM132PV |
0.8 |
116 |
8.88-22.21 |
314-784 |
132 |
180 |
78 |
2350 |
DN50 |
30 |
2500×1400×1580 |
2 1/2? |
|
1 |
145 |
8.15-20.38 |
288-720 |
|||||||||
|
1.25 |
181 |
7.31-18.29 |
258-646 |
|||||||||
|
CM160PV |
0.8 |
116 |
11.54-28.85 |
407-1019 |
160 |
220 |
78 |
3720 |
DN80 |
35 |
3100×1700×2090 |
DN100 |
|
1 |
145 |
9.81-24.52 |
346-866 |
|||||||||
|
1.25 |
181 |
8.87-22.17 |
313-783 |
|||||||||
|
CM200PV |
0.8 |
116 |
14.65-36.63 |
517-1293 |
200 |
270 |
78 |
3750 |
DN80 |
43 |
3100×1700×2090 |
DN100 |
|
1 |
145 |
13.10-32.70 |
463-1155 |
|||||||||
|
1.25 |
181 |
11.09-27.72 |
392-979 |
|||||||||
|
CM250PV |
0.8 |
116 |
17.15-42.88 |
606-1514 |
250 |
340 |
78 |
3900 |
DN80 |
53 |
3100×1700×2090 |
DN100 |
|
1 |
145 |
15.60-39.00 |
551-1377 |
|||||||||
|
1.25 |
181 |
13.87-34.64 |
490-1223 |
|||||||||
|
CM320PV |
0.8 |
116 |
23.64-59.10 |
835-2087 |
320 |
430 |
80 |
4850 |
DN100 |
60 |
3600×2800×2000 |
DN125 |
|
1 |
145 |
21.40-53.50 |
756-1889 |
|||||||||
|
1.25 |
181 |
19.30-48.25 |
681-1704 |
|||||||||
